12
Sub Menu Units Range Defaults
SETTINGS
*1 Low Press Shutdown % or Units From 0 to Cut In Pressure 50.0%
*2 Cut In Pressure %
From Low Pressure Shutdown to
99.9% of Set Point
75.0%
Set Point Unitless 0 - 9999 300
*2 High Pressure Limit %
100.1% of Set Point to High Press
Shutdown
150.0%
*2 High Press Shutdown % High Pressure Limit to 300% 200.0%
Pump Flow Rate /Sec 0 - 9999, Flow Meter 99
* Friction Loss Unitless 0 - 999 0
* Set Point 2 Unitless 0 - 9999 400
* Set Point 3 Unitless 0 - 9999 400
* Set Point 4 Unitless 0 - 9999 400
* Set Point 5 Unitless 0 - 9999 400
* Set Point 6 Unitless 0 - 9999 400
* Set Point 7 Unitless 0 - 9999 400
* Set Point 8 Unitless 0 - 9999 400
* Pressure Trip 1 Low Unitless 0 - 9999 100
* Pressure Trip 1 High Unitless 0 - 9999 200
* Pressure Trip 2 Low Unitless 0 - 9999 500
* Pressure Trip 2 High Unitless 0 - 9999 600
* Flow Trip Low /Sec 0 - 9999 100
* Flow Trip High /Sec 0 - 9999 200
* These menus are related to other settings. They are not visible unless related settings are enabled
*1 Low pressure shutdown can either be a fixed pressure value or a proportion of the set point. Pressing
Up and Down together will toggle between fixed and proportional mode. Default is proportional mode.
*2 These menus are proportions of set point; They show a computed pressure in brackets to the right of
the second line of the display. This computation is always based off Set Point 1. However when running
the value calculated will be based off the current set point.
