27

Minimum Frequency or Shutoff Head

The minimum frequency is the lowest setting at which a pump will begin to contribute to the system pressure.
This value is expressed as a percentage.
This is the minimum frequency at which the Speedman determines that a pump is to be stopped as at this
speed it is not contributing flow.

There are two ways to setup the Minimum Frequency,
“Fixed” or “Calculated”; this is selected by editing the “Min Freq Mode” option in the Configuration Menu.

Fixed - a fixed valve is selected for all set points.
The pump minimum frequency (Hz) can be found in your pump’s data sheet.
Divide this minimum value by the maximum speed of the pump (Hz) and
multiply the result 100 to get minimum frequency (%). Enter this value

Calculated - The Shutoff Head of the pump is entered and the Min Frequency
is then calculated based on the Shutoff Head value and the current set point.
The actual calculated minimum pump speed is shown on the right hand side of
the display.

Response Rate (Proportional)

The response rate is a figure used to set the speed of reaction of the system.
It is expressed as a percentage ranging from 0.1 - 100.0.
0.1 is the slowest response and 100.0 the fastest.
The current pressure reading is also displayed to assist while tuning – Shown above as “nn”

Acceleration

The acceleration of the VSD can be limited by this figure. It is designed to
Brake the PID control. It is used in cases where the Acceleration needs to be
dampened. The figure is input in %/second.

High Pressure Restarts

This setting allows the operator to set the number of times that the system can
shutdown and automatically restart after a High Pressure Shutdown.
The range is from Off to 1-250.
”Off” - the system shuts down after the High Pressure delay timer trips (default).
“Automatic restart” – (per hr) The Speedman will allow “X” restarts in an hour commencing from the first
High Pressure Fault. A message “New Fault” appears on the main screen on each restart and is logged in the
fault log.

Min Frequency
XX.X %

Shutoff Head
XXXX (XX.X%)

Response Rate
XXX.X % (nn)

Acceleration
XXX %/Sec

HiPress Restarts
XXX

TUNING

Minimum Frequency

%

0.0 - 100.0

45.0

Shutoff Head

Unitless

0 - 9999

1924

Response Rate

%

0.1 - 100.0

2.0

Acceleration

%/second

1 - 100

20

High Press Restarts

number

Off, 1 - 250

Off

Standby Boost

% of Setpoint

10 - 250

20

Standby Flow Min

/Sec

0 - 9999

200

Error Correction (I

seconds

Off, 0.1 - 100.0

3.0

Overshoot Elimination (D

%

Off, 0.1 - 50.00

15.0

RP(P) EC(I) OE(D

number

-1000, 1000

display
