7.9.3 Checking Input Contacts

Follow Table 7.10 to check the input contacts. The table uses an example with input contact 1.

Table 7.10

Checking Input Contacts

Switch operation

Display

Description

>

ENT

A

01

Display after the password has been entered.

>

ENT

G

01

Touch the [∧] key to switch to Group G.

>

ENT

G

0

1

Touch the [>] key to move the position of the digit that is flashing to the right one
digit.

>

ENT

G

2

1

Touch the [∧] key to enter 2.

>

ENT

0

Touch the [ENT] key. 0 is displayed with the contact open. If the contact is closed,
the display will be 1 (one).
This enables you to check whether or not the wiring connections have been
properly made or not.

>

ENT

G

21

Touch the [ENT] key once again to switch to the parameter code selection display.

>

ENT

Basic

panel

display

Touch the [>] key together with the [ENT] key to return to the basic panel display.

The symbol [

] indicates that the key is being touched. Light characters indicates that the digits are flashing.
