Equipment Setup and Others in Group F
Code
Item
Tuning
Engineering unit
Default setting
F01
Equipment setup
0 Oxygen analyzer
Oxygen analyzer
1 Humidity analyzer
F02
Selection of measurement
gas
0 Wet
Wet
1 Dry
F04
Selection of temperature
units
0 degree C
degree C
1 degree F
F05
Selection of pressure units 0 kPa
kPa
1 psi
F08 Selection of display items
0 Oxygen concentration
Oxygen
concentration
1 Amount of moisture quantity
2 Mixed ratio
3 Item selected with analog output
F10
Date
YY.MM.DD/HH.MM
F11 Period over which average
values are calculated
1 to 255 hours
Hours
One hour
F12 Period over which max.
and min. values are
monitored
1 to 255 hours
Hours
24 hours
F15
Purging time
0 to 60 minutes
Minutes
0 minute
F20 Amount of water vapor in
exhaust gas
0 to 5
m
3
/kg (m
3
)
1.0 m
3
/kg (m
3
)
F21 Theoretical amount of air
0 to 20
m
3
/kg (m
3
)
1.0 m
3
/kg (m
3
)
F22 X value
0 to 19.99
1
F23 Absolute humidity of the
atmosphere
0 to 1
kg/kg
0.1 kg/kg
F30 Initializing all data
F31 Initializing data in group A
F32 Initializing data in group B
F33 Initializing data in group C
F34 Initializing data in group D
F35 Initializing data in group E
F36 Initializing data in group F
Inspection-related Items in Group G
Code
Item
Tuning
Engineering unit
Default setting
G01 mA-output loop
4 to 20
mA
4 mA
G11
Output contact 1
0 Open
Open
1 Closed
G12
Output contact 2
0 Open
Open
1 Closed
G15 Automatic calibration
solenoid valve (zero)
0 Off
Off
1 On
G16 Automatic calibration
solenoid valve (span)
0 Off
Off
1 On
G21
Input1 contact
0 Open
1 Closed
G22
Input2 contact
0 Open
1 Closed
G30 Reset
