P age 77
K INO-P V-D5253-D4253 Mini-ITX Motherboard
 P C I-E Mini C ard 2 C ontrol [E nabled]
The PCI-E Mini Card 2 Control option can help to enable or disable Mini PCI-E support.

Disabled The spread spectrum mode is disabled

Enabled D EFAULT The spread spectrum mode is enabled
5.4.3 Intel IG D S WS C I OpR egion
Use the Intel IGD SWSCI OpRegion menu to configure the video device connected to the
system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT Mode Select
[DVMT Mode]
DVMT/Fixed Memory [256 MB]
Select DVMT Mode/Fixed
Mode
---------------------
: Select Screen
↑ ↓: Select Item
Enter
:Select
+/-: Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 16: South Bridge Chipset Configuration
 DVMT Mode S elect [DVMT Mode]
Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology
(DVMT) operating mode.

Fixed
Mode
A fixed portion of graphics memory is reserved as
graphics memory.

DVMT
Mode
D EFAULT Graphics memory is dynamically allocated according
to the system and graphics needs.
