P age 70
K INO-P V-D5253-D4253 Mini-ITX Motherboard

IO=3BCh;
IRQ=7
Parallel Port I/O port address is 3BCh and the
interrupt address is IRQ7
 Device Mode [P rinter Mode]
Use the Device Mode option to select the mode the parallel port operates in.
Configuration options are listed below.
 Printer Mode Default
 SPP Mode
 EPP-1.9 and SPP Mode
 EPP-1.7 and SPP Mode
 ECP Mode
 ECP and EPP 1.9 Mode
 ECP and EPP 1.7 Mode
5.3.7 H/W Monitor
The H/W Monitor menu (BIOS Menu 11) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+49 C
SYS Temperature :+61 C
CPU FAN Speed :N/A
VCC3V :+3.344 V
V_core :+1.176 V
Vcc :+5.045 V
Vcc12 :+12.144 V
V1_5VDDR :+1.600 V
VSB3V :+3.344 V
VBAT :+3.248 V
CPU Smart Fan control [Auto Mode]
Temperature Bound1 60
Temperature Bound2 50
Temperature Bound3 40
Temperature Bound4 30
---------------------
: Select Screen
↑ ↓: Select Item
Enter
:Select
+/-: Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 11: Hardware Health Configuration
