P age 15
K INO-P V-D5253-D4253 Mini-ITX Motherboard
C onnector T ype L abel
Battery connector 2-pin wafer BAT1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 3-pin wafer SYS_FAN1
Standard ATX power connector 20-pin connector JATXPWR1
Digital I/O connector 10-pin header DIO1
Front panel connector 8-pin header F_PANEL1
Memory slot 204-pin DDR3 DIMM slot DIMM1, DIMM2
Parallel port connector 26-pin header LPT1
RS-232/422/485 serial port connector 14-pin header COM6
SATA drive connectors 7-pin SATA drive connectors SATA1, SATA2,
SMBus connector 4-pin wafer SMB1
SPI Flash connector 8-pin header SPI1
SPI Flash connector 8-pin header JSPI2
USB connector 8-pin header USB67
TPM connector 20-pin connector TPM1
KB/MS wafer 6-pin header KB_MS1
PCI slot PCI slot PCI1
PCIe x1 slot PCIe x1 slot PCIE1
PCIe Mini slot PCIe Mini slot MINIPCIE1
PCIe Mini slot PCIe Mini slot MINIPCIE2
Table 3–1: Internal Peripheral Connectors
3.1.3 E xternal Interface P anel C onnectors
The table below lists the connectors on the external I/O panel.
C onnector T ype L abel
Audio connector Audio jack JAUDIO1
