P age 3

K INO-P V-D5253-D4253 Mini-ITX Motherboard

1.3 Features

Some of the KINO-PV-D5253/D4253 motherboard features are listed below:

 Mini-ITX form factor

 Intel® Atom™ D525 /D425 Processor

 Supports two DDR3 SODIMM

 Three Gigabit Ethernet connectors

 Two SATA connectors

 Eight USB ports

 Six serial ports

 RoHS compliant

1.4 C onnectors

The connectors on the KINO-PV-D5253/D4253 are shown in the figure below.

Figure 1-2: Connectors
