P age 17

K INO-P V-D5253-D4253 Mini-ITX Motherboard

Figure 3-2: Battery Connector Location

Pin

Description

1

Battery+ (+3V)

2

Ground

Table 3-3: Battery Connector Pinouts

3.2.2 C P U F an C onnector

C N L abel:

C P U_F AN1

C N T ype:

4-pin wafer

C N L ocation:

See Figure 3-3

C N P inouts :

See Table 3-4

The fan connector attaches to a CPU cooling fan.
