P age 58
K INO-P V-D5253-D4253 Mini-ITX Motherboard
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
ACPI Sleep State
[S3 (Suspend to RAM)]
Select the highest ACPI
sleep state the system
will enter, when the
SUSPEND button is
pressed.
----------------------
: Select Screen
↑ ↓: Select Item
Enter
:Select
+/-: Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.01.1204. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 3: ACPI Settings
 AC P I S leep S tate [S 3 (S us pend to R AM)]
Use the ACPI Sleep State option to specify the sleep state the system enters when it is
not being used.

Suspend Disabled

S1 (CPU Stop
Clock)
The system enters S1(POS) sleep state. The
system appears off. The CPU is stopped; RAM is
refreshed; the system is running in a low power
mode.

S3 (Suspend to
RAM)
D EFAULT The caches are flushed and the CPU is powered
off. Power to the RAM is maintained. The
computer returns slower to a working state, but
more power is saved.
5.3.2 Trus ted C omputing
Use the Trusted Computing menu (BIOS Menu 4) to configure settings related to the
Trusted Computing Group (TCG) Trusted Platform Module (TPM).
