P age 55
K INO-P V-D5253-D4253 Mini-ITX Motherboard
K ey F unction
F4 key Save all the CMOS changes
Table 5-1: BIOS Navigation Keys
5.1.3 G etting Help
When F1 is pressed a small help window describing the appropriate keys to use and the
possible selections for the highlighted item appears. To exit the Help Window press E SC or
the F1 key again.
5.1.4 Unable to R eboot after C onfiguration C hanges
If the computer cannot boot after changes to the system configuration is made, CMOS
defaults. Use the jumper described in Chapter 4.
5.1.5 B IOS Menu B ar
The menu bar on top of the BIOS screen has the following main items:
 Main – Changes the basic system configuration.
 Advanced – Changes the advanced system settings.
 PCIPnP – Changes the advanced PCI/PnP Settings
 Boot – Changes the system boot configuration.
 Security – Sets User and Supervisor Passwords.
 Chipset – Changes the chipset settings.
 Power – Changes power management settings.
 Exit – Selects exit options and loads default settings
The following sections completely describe the configuration options found in the menu
items at the top of the BIOS screen and listed above.
