P age 63
K INO-P V-D5253-D4253 Mini-ITX Motherboard
 L egacy US B S upport [E nabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard
support. Normally if this option is not enabled, any attached USB mouse or USB keyboard
does not become available until a USB compatible operating system is fully booted with all
USB drivers loaded. When this option is enabled, any attached USB mouse or USB
keyboard can control the system even when there is no USB driver loaded onto the
system.

Enabled D EFAULT Legacy USB support enabled

Disabled Legacy USB support disabled

Auto Legacy USB support disabled if no USB devices are
connected
5.3.6 S uper IO C onfiguration
Use the Super IO Configuration menu (BIOS Menu 8) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip
Finteck F81865
> Serial Port 0 Configuration
> Serial Port 1 Configuration
> Serial Port 2 Configuration
> Serial Port 3 Configuration
> Serial Port 4 Configuration
> Serial Port 5 Configuration
> Parallel Port Configuration
Set Parameters of Serial
Port 0 (COMA)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
:Select
+/-: Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 8: Super IO Configuration
