P age 45

K INO-P V-D5253-D4253 Mini-ITX Motherboard

Figure 4-5: SATA Drive Cable Connection

Connect the cable to the SATA disk. Connect the connector on the other end of the

cable to the connector at the back of the SATA drive. See Figure 4-6.

Connect the SATA power cable. Connect the SATA power connector to the back of the

SATA drive. See Figure 4-6.
