K INO-P V-D5253-D4253 Mini-ITX Motherboard

1.6 Data Flow

Figure 1-4 shows the data flow between the system chipset, the CPU and other

components installed on the motherboard.

Figure 1-4: Data Flow Diagram

1.7 Technical S pecifications

KINO-PV-D5253/D4253 technical specifications are shown below.

S pecification

K INO-P V-D5253/D4253

F orm F actor

Mini-ITX
