P age 69
K INO-P V-D5253-D4253 Mini-ITX Motherboard
5.3.6.2 P arallel P ort C onfiguration
Use the Parallel Port Configuration menu (BIOS Menu 10) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=7
Change Settings
[Auto]
Device Mode [Printer Mode]
Enable or Disable
Parallel Port(LPT/LPTE)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
:Select
+/-: Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: Parallel Port Configuration Menu
 P arallel P ort [E nabled]
Use the Parallel Port option to enable or disable the parallel port.

Disabled Disable the parallel port

Enabled D EFAULT Enable the parallel port
 C hange S ettings [Auto]
Use the Change Settings option to change the parallel port IO port address and interrupt
address.

Auto D EFAULT The parallel port IO port address and interrupt
address are automatically detected.

IO=378h;
IRQ=7
Parallel Port I/O port address is 378h and the
interrupt address is IRQ7

IO=278h;
IRQ=7
Parallel Port I/O port address is 278h and the
interrupt address is IRQ7
