5.4.1 Northbridge Configuration
Use the Northbridge Chipset Configuration menu (BIOS Menu 13) to configure the
Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Chipset
Memory Information
CPU Type
Clarksfield
Total Memory
2048 MB (DDR3 1333)
Memory Slot0
2048 MB (DDR3 1333)
Memory Slot2 0 MB (DDR3 1333)
CAS# Latency(tCL)
9
RAS# Active Time(tRAS) 24
Row Precharge Time(tRP) 9
RAS# to CAS# Delay(tRCD) 9
Write Recovery Time(tWR) 10
Row Refresh Cycle Time(tRFC) 74
Write to Read Delay(tWTR) 5
Active to Active Delay(tRRD) 4
Read CAS# Precharge(tRTP) 5
Initate Graphic Adapter
[PEG/IGD]
Select which graphics
controller to use as the
primary boot device.
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 13:Northbridge Chipset Configuration
 Initiate Graphics Adapter [PEG/IGD]
Use the Initiate Graphics Adapter option to select the graphics controller used as the
primary boot device. Select either an integrated graphics controller (IGD) or a combination
of PCI graphics controller, a PCI express (PEG) controller or an IGD. Configuration
options are listed below:
 IGD
 PEG/IGD D EFAULT
5.4.2 Southbridge Configuration
Use the Southbridge Configuration menu (BIOS Menu 14) to configure the Southbridge
chipset.
