IEI Integration KINO-HM551 User Manual
Kino-hm551, User manual, Model
KINO-HM551
Page I
IEI Technology Corp.
User Manual
KINO-HM551
MODEL:
Mini-ITX SBC Supports Socket G1 for Intel® mobile Core™ i7/i5/i3 and
Intel® Celeron®, VGA/DVI/LVDS/HDMI Display, Dual GbE, Eight USB
2.0, Dual PCIe Mini, Four SATA 3Gb/s, Audio, RoHS
Rev. 1.02 - 15 February, 2012
)zKINO-HM551 CPU Card
Table of contents
Document Outline
- 1 Introduction
- 2 Unpacking
- 3 Connectors
- 3.1 Peripheral Interface Connectors
- 3.2 Internal Peripheral Connectors
- 3.2.1 Audio Connector
- 3.2.2 Digital I/O Connector
- 3.2.3 Fan Connector (CPU)
- 3.2.4 Fan Connector (System)
- 3.2.5 Front Panel Indicators
- 3.2.6 Half PCIe Mini Card Slot
- 3.2.7 Infrared Connector
- 3.2.8 Inverter Connector
- 3.2.9 Keyboard/Mouse Connector
- 3.2.10 LVDS Connector
- 3.2.11 PCIe Mini Card Slot
- 3.2.12 Power Supply Connector
- 3.2.13 RS-232/422/485 Serial Port Connector
- 3.2.14 RS-232 Serial Port Connector
- 3.2.15 SATA Drive Connectors
- 3.2.16 SATA Power Connectors
- 3.2.17 SMBus Connector
- 3.2.18 SPDIF Connector
- 3.2.19 TPM Connector
- 3.2.20 USB Connectors
- 3.3 External Peripheral Interface Connector Panel
- 4 Installation
- 5 BIOS Screens
- A BIOS Menu Options
- B One Key Recovery
- C Terminology
- D Watchdog Timer
- E Hazardous Materials Disclosure
