KINO-HM551
Page 20
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
21 GND 22 PCIRST#
23 PERN2 24 3VDual
25 PERP2 26 GND
27 GND 28 1.5 V
29 GND 30 SMBCLK
31 PETN2 32 SMBDATA
33 PETP2 34 GND
35 GND 36 USBD-
37 N/C 38 USBD+
39 N/C 40 GND
41 N/C 42 N/C
43 N/C 44 N/C
45 N/C 46 N/C
47 N/C 48 1.5 V
49 N/C 50 GND
51 N/C 52 VCC3
Table 3-8: Half PCIe Mini Card Slot Pinouts
3.2.7 Infrared Connector
CN Label: IR1
CN Type: 5-pin header
CN Location: See Figure 3-8
CN Pinouts: See Table 3-9
The infrared connector attaches to an infrared receiver for use with remote controls.
