Table 3-28: vga connector pinouts, Table 3-29: dvi connector pinouts – IEI Integration KINO-HM551 User Manual
Page 52

KINO-HM551
Page 38
PIN NO.
DESCRIPTION PIN NO. DESCRIPTION
11
NC
12
DDCDAT
13
HSYNC
14
VSYNC
15
DDCCLK
Table 3-28: VGA Connector Pinouts
The DVI (Digital Visual Interface) port connects to a monitor that supports DVI video input.
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DVI signal differential pair (2-)
2
DVI signal differential pair (2+)
3
GND
4
DVI signal differential pair (4-)
5
DVI signal differential pair (4+)
6
DDCLCK
7
DDCDATA
8
N/C
9
DVI signal differential pair (1-)
10
DVI signal differential pair (1+)
11
GND
12
DVI signal differential pair (3-)
13
DVI signal differential pair (3+)
14
5V supply
15
GND
16
Hot plug detect
17
DVI signal differential pair (0-)
18
DVI signal differential pair (0+)
19
GND
20
DVI signal differential pair (5-)
21
DVI signal differential pair (5+)
22
GND
23
DVI CLK(+)
24
DVI CLK(-)
Table 3-29: DVI Connector Pinouts
