KINO-HM551
Page 87
 Set Spread Spectrum [Disabled]
Use the Set Spread Spectrum function option to reduce the EMI. Excess EMI is
generated when the system clock generator pulses have extreme values. Spreading the
pulse spectrum modulates changes in the extreme values from spikes to flat curves, thus
reducing the EMI. This benefit may in some cases be outweighed by problems with
timing-critical devices, such as a clock-sensitive SCSI device.

Disabled D EFAULT EMI not reduced

Enabled EMI reduced
5.4.3 Intel IGD SWSCI OpRegion
Use the Intel IGD SWSCI OpRegion menu to configure the video device connected to the
system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT/FIXED Memory
[Maximum]
Active LFP [Enable LVDS]
LCD Panel Type [Select by Panel ID]
Panel ID Resolution 1024x768 24bit
Select the DVMT/FIXED
Mode Memory size used by
Internal Graphics Device
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 15: Intel IGD SWSCI OpRegion
 DVMT/FIXED Memory [Maximum]
Use the DVMT/FIXED Memory option to select memory size used by the Internal
Graphics Device. Configuration options are listed below.
 128 MB
