KINO-HM551
Page 69
5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.3.7 0.16
Project Version B186AR10.ROM
Build Date 08/31/2010 13:33:34
Memory Information
Total Memory
2048 MB (DDR3 1333)
System Date
[Sun 01/30/2011]
System Time [01:33:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Data
elements.
----------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 1: Main
 BIOS Information
The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information
cannot be changed. The items shown in the system overview include:
 BIOS Vendor: Installed BIOS vendor
 Core Version: Current BIOS version
 Project Version: the board version
 Build Date: Date the current BIOS version was made
 Memory Information
The Memory Information lists a brief summary of the on-board memory. The fields in
Memory Information cannot be changed.
 Total Memory: Displays the auto-detected system memory size and type.
The System Overview field also has two user configurable fields:
