5.3.7.2 Console Redirection Settings
The Console Redirection Settings menu (BIOS Menu 11) allows the console redirection
options to be configured. The option is active when Console Redirection option is enabled.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Serial port 0
Console Redirection Settings
Terminal Type
[ANSI]
Bits per second [115200]
Data Bits [8]
Parity [None]
Stop Bits
[1]
Emulation: ANSI:
Extended ASCII char set.
VT100: ASCII char set.
VT100+: Extends VT100 to
support color, function
keys, etc. VT-UTF8: Uses
UTF8 encoding to map
Unicode chars onto 1 or
more bytes.
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 11: Console Redirection Settings
 Terminal Type [ANSI]
Use the Terminal Type option to specify the remote terminal type.

VT100 The target terminal type is VT100

VT100+ The target terminal type is VT100+

VT-UTF8 The target terminal type is VT-UTF8

ANSI D EFAULT The target terminal type is ANSI
 Bits per second [115200]
Use the Bits per second option to specify the transmission speed of the serial port.
