KINO-HM551
Page 6
1.5 Technical Specifications
KINO-HM551 technical specifications are listed in table below.
Specification KINO-HM551
Form Factor Mini-ITX
Socket Socket G1 (rPGA989)
Socket 988A
CPU Supported 32 nm Intel® Core™ i3 processor
32 nm Intel® Core™ i5 processor
32 nm Intel® Core™ i7 processor (i7 processors without
integrated graphics)
Intel® Celeron® processor
Express Chipset Intel® HM55
Memory Two 204-pin SO-DIMM sockets support 800/1066 MHz
4.0 GB (max.) dual-channel DDR3 SDRAM SO-DIMM
(system max. 8GB)
Audio Realtek ALC888 HD 7.1 channel audio codec
LAN Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0
support on LAN1
Super I/O Fintek F81865
BIOS AMI uEFI BIOS label
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCIe Two PCIe Mini slot
I/O Interface Connectors
Audio Connector One internal audio connector (10-pin header)
