KINO-HM551
Page 7
Specification KINO-HM551
Display Ports One VGA port (2048x1536)
One HDMI port (up to 1080p)
One internal LVDS connector (1600x1200)
One DVI-D port (1600x1200)
Ethernet Two RJ-45 GbE ports
Serial Ports Three RS-232 via three 10-pin headers
One external RS-232 serial connector via DB-9 male
Two RS-232/422/485 via 14–pin header
USB 2.0/1.1 Ports Four external USB ports
Four internal USB ports via two 8-pin headers
Storage
Serial ATA Four SATA 3.0 Gb/s connectors
Two 5 V SATA power connectors
Environmental and Power Specifications
Power Supply 12 V DC input only
ATX and AT power supported
Power Connector One external DIN 4-pin DC jack
One internal 4-pin Molex power connector for power supply
Power Consumption [email protected] (2.66 GHz Intel® Core™ i7 620M CPU with two
1333 MHz 4 GB DDR3 SO-DIMM)
Operating Temperature -10ºC ~ 60ºC (requires cooler and silicone heat sink paste)
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 170 mm x 170 mm
Weight GW/NW 900 g / 450 g
Table 1-1: Technical Specifications
