KINO-HM551
Page 14
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
Audio connector 10-pin header FRONT-PANEL1
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 3-pin wafer SYS_FAN1
Front Panel indicators 10-pin header F_PANEL1
Half PCIe Mini card slot PCIe Mini card slot CN4
Infrared connector 5-pin header IR1
Inverter connector 5-pin wafer INVERTER1
Keyboard and mouse connector 6-pin wafer KB_MS1
LVDS connector 30-pin crimp LVDS1
PCIe Mini card slot PCIe Mini card slot CN3
Power supply connector 4-pin connector PWR2
RS-232/422/485 serial port connector 14-pin header COM4, COM6
RS-232 serial port connector 10-pin header COM2, COM3, COM5
Serial ATA (SATA) drive connector 7-pin SATA
S_ATA1, S_ATA2,
S_ATA5, S_ATA6
SATA power connector 4-pin wafer CN5, CN6
SMBus connector 4-pin wafer CN7
SPDIF connector 5-pin connector SPDIF1
TPM connector 20-pin connector TPM1
USB connectors 8-pin header USB1, USB2
