5.6.3 CPU Card Installation
To install the PICOe-GM45A CPU card onto the backplane, carefully align the CPU card
interface connectors with the corresponding socket on the backplane. To do this, please
refer to the reference material that came with the backplane. Next, secure the CPU card to
the chassis. To do this, please refer to the reference material that came with the chassis.
5.7 Internal Peripheral Device Connections
5.7.1 Peripheral Device Cables
The cables listed in
850H809H
Table 5-7 are shipped with the PICOe-GM45A.
Quantity Type
1 Keyboard and Mouse cable
2 SATA drive cable
1 SATA power cable
1 Dual port USB cable
1 Dual RS-232 cable
Table 5-7: IEI Provided Cables
Some optional items that can be purchased separately and installed on the
PICOe-GM45A include:
