PICOe-GM45A Half-Size CPU Card
Page 134
19200 8,n,1
09600 8,n,1
NOTE:
Identical baud rate setting musts be set on the host (a management
computer running a terminal software) and the slave
Redirection After BIOS POST [Always]
Use the Redirection After BIOS POST option to specify when console redirection should
occur.
Disabled The console is not redirected after POST
Boot Loader Redirection is active during POST and during Boot
Loader
Always D EFAULT Redirection is always active (Some OSes may not
work if set to Always)
Terminal Type [ANSI]
Use the Terminal Type BIOS option to specify the remote terminal type.
ANSI D EFAULT The target terminal type is ANSI
VT100 The target terminal type is VT100
VT-UTF8 The target terminal type is VT-UTF8
