PICOe-GM45A Half-Size CPU Card
Page 24
Display
VGA integrated in Intel® GM45
18-bit or 24-bit dual-channel LVDS integrated in Intel® GM45
HDTV with 1080i maximum resolution supported
SDVO interface supported
BIOS AMI BIOS label
Audio
7.1 channel HD audio kit with Realtek ALC883 codec supports
dual audio streams
LAN Two Intel® 82574L PCIe GbE controllers
COM Two RS-232 serial ports
USB2.0
Seven USB 2.0 devices supported:
Six by onboard pin-headers
One by external connector
SATA Four 3.0 Gbps SATA II drives supported
Keyboard/mouse
One external PS/2 connector
One 6-pin header
Parallel Port One 26-pin parallel port connector
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output
through the ITE IT8718F super I/O
Watchdog Timer Software programmable 1-255 sec. through the ITE super I/O
Infrared
One infrared connector through the ITE super I/O. Supports:
Serial Infrared (SIR)
Amplitude Shift Keyed IR (ASKIR)
Power Supply ATX and AT power supported
Power Consumption
5V @ 10.21A, [email protected]
( 2.2 GHz Intel® Core™2 Duo T7500 CPU with a 800 MHz FSB
and two 2 GB 800 MHz DDR2 DIMMs, 3D Mark 2001SE )
