PICOe-GM45A Half-Size CPU Card
Page 46
Maximum Operating Temperature: 60°C (140°F)
A heat sink must be installed on the CPU. Thermal paste must be smeared on the lower
side of the heat sink before it is mounted on the CPU. Heat sinks are also mounted on the
Northbridge and Southbridge chipsets to ensure the operating temperature of these chips
remain low.
2.8.3 Power Consumption
762H723H
Table 2-1 shows the power consumption parameters for the PICOe-GM45A running with
a 2.2 GHz Intel® Core™2 Duo processor T7500 with a 800 MHz FSB and two 2.0 GB
800 MHz DDR2 memory.
Voltage Current
+5V 10.21A
+12V 0.11A
Table 2-1: Power Consumption
