PICOe-GM45A Half-Size CPU Card
Page 23
1 x SPI Flash connector
1 x TV Out connector
3 x USB 2.0 connectors (supports six USB 2.0 devices)
The PICOe-GM45A has the following external peripheral interface connectors on the
board rear panel.
2 x Ethernet connectors
1 x PS/2 connector
1 x USB connector
1 x VGA connector
The PICOe-GM45A has the following on-board jumpers:
AT power selection
Clear CMOS
LVDS voltage selection
LVDS panel resolution selection
PCIe interface setup
1.2.3 Technical Specifications
PICOe-GM45A technical specifications are listed in
747H709H
Table 1-1. See Chapter 2 for details.
Specification PICOe-GM45A
System CPU
45 nm Socket P Intel® Core™2 Duo processor or
Intel® Celeron® M processor
Front Side Bus (FSB) 1066 MHz (Max.), 800 MHz or 533 MHz
System Chipset
Northbridge: Intel® GM45
Southbridge: Intel® ICH9M
Memory
Two 240-pin DIMM sockets support two 667/800 MHz 2.0 GB
(max.) DDR2 SDRAM DIMM (system max. 4 GB)
Super I/O ITE IT8718F
