5.5.1 AT Power Select Jumper Settings
NOTE:
The AT Power Select Jumper is the same as the ATX Enable
connector.
Jumper Label: ATXCTl1
Jumper Type: 3-pin wafer
Jumper Settings: See
789H
Table 5-2
Jumper Location: See
790H
Figure 5-6
The AT Power Select jumper specifies the systems power mode as AT or ATX. Use a
jumper cap to short pin 1 - pin 2 on the ATXCTL1 connector to enable the AT Power mode
on the system. In the ATX mode use the PS_ON- and 5VSB cable. AT Power Select
jumper settings are shown in
791H
Table 5-2.
AT Power Select Description
Short 1 – 2 Use AT power Default
Open Use ATX power
Table 5-2: AT Power Select Jumper Settings
The location of the AT Power Select jumper is shown in
792H
Figure 5-6 below.
