PICOe-GM45A Half-Size CPU Card

Page 93

5.5.4 LVDS Voltage Selection

WARNING:

Permanent damage to the screen and PICOe-GM45A may occur if the

wrong voltage is selected with this jumper. Please refer to the user

guide that cam with the monitor to select the correct voltage.

Jumper Label:

J_VLVDS1

Jumper Type:

3-pin header

Jumper Settings:

See

801H

Table 5-5

Jumper Location:

See

802H

Figure 5-9

The LVDS Voltage Selection jumpers allow the LVDS screen voltages to be set.

J_VLVDS1 sets the voltage connected to LVDS1. The LVDS Voltage Selection jumper

settings are shown in

803H

Table 5-5.

LCD Voltage Select

Description

Short 1-2

+3.3V LVDS

Default

Short 2-3

+5V LVDS

Table 5-5: LVDS Voltage Selection Jumper Settings

The LVDS Voltage Selection jumper location is shown in

804H

Figure 5-9.
