Disassembling the System Brick Assembly
Refer to the diagrams beginning on page 3-33 for details.
System Brick Replacement Parts
Diagram number
Part Number
Description
Torque
1
1009-0910-02
Assembly, Shielded Analog System Board, 3/5 Lead
2
9310-0883
Isolator, PD Engine to Analog PCB
3
9310-0796
Standoff, Male (single use only)
6 inch-lbs
4
9310-0797
Standoff, Female (single use only)
5
1009-0909-01
Assembly, PD Engine, Capacitor
6
9301-0509-01
Assembly, PCB, Digital Board
7
0163-0429
Scr. #5-20 X 0.250"
4 inch-lbs
8
N/A
N/A
9
9310-0798
Post, Corner
10
0163-1222
Scr. #5-20 X 3/8"
6 inch-lbs
11
9330-0768
Spacer
12
3005-0001
MS-11 Board
13
9330-0762
Adhesive, SpO
2
, PCB
14
9310-0889
Isolator, SpO
2
, PCB
15
9330-0763
Adhesive, SpO
2
, Isolator
16
9320-0744
Bracket, Heatsink (SpO
2
only)
17
9330-0737
Pad, 1.00 X .50, Rubber
18
9320-0765
Bracket, Heatsink and Parameter PCB Mounting
