R Series Service Manual
1-12
9650-0903-01 Rev. J
Test Setup for Off Current Test:
1. Remove 0.1
resistor and replace with 1K
.
2.
Connect DMM across resistor.
3.
Set voltage scale to DCV.
4.
Measure voltage across resistor.
Charger Test
Tools Needed: 2-Post Battery Fixture (9100-0575-TF), DVM, 2 Test Leads, Impulse 4000, Stopwatch.
Test Setup:
Set DVM to read DC Volts.
Connect Postive lead to positive post of the R Series charger load fixture.
Connect negative lead to negative post of the R Series charger load fixture.
Verify the unit is plugged into AC Power.
Do this...
Observe this...
Pass/Fail
4.10
Off Current Test
Measure across resistor with unit turned off.
Voltage should be less than 270 mV (<270
A of current).
o
o
Record your results on the Maintenance Test Checklist.
Do this...
Observe this...
Pass/Fail
4.11
Set front panel switch to DEFIB or ON, (for BLS
units, press MANUAL MODE, then press
CONFIRM).
4.12
Install Charger Test Fixture.
