C HAPTER 1 G ENERAL I NFORMATION
1–2 www.zoll.com 9650-0904-01 Rev. K
up. When operating in the manual configuration, the device operates as a conventional
defibrillator where the device’s charging and discharging are fully controlled by the operator. In
advisory mode, some of the features of the device are automated and a sophisticated algorithm
is used to identify shockable ECG rhythms (VF and wide complex VT >150 bpm) that should
be treated by defibrillator shock delivery. Depending on local protocols, the unit may be
configured to automatically analyze the ECG, charge the defibrillator (if appropriate), and
prompt the operator to PRESS SHOCK between periods of CPR.
The R Series unit assists caregivers during cardiopulmonary resuscitation (CPR) by evaluating
the rate and depth of chest compressions and providing feedback to the rescuer.
Real CPR Help
®
requires the use of OneStep™ CPR electrodes or OneStep™ Complete
electrodes. When using these pads, the displayed ECG waveforms can be adaptively filtered,
using the See-Thru CPR
®
feature, to reduce the artifact caused by chest compressions.
The R Series is a Code-Ready
®
defibrillator. It extends testing beyond shock delivery and
checks more than 40 measures of readiness, including the presence of the correct cables and
electrodes, the type of electrode, and other important electronic functions. The R Series also
verifies the condition and expiration date of OneStep electrodes. This code readiness testing
can occur automatically, without disconnecting electrodes or paddles, or requiring additional
equipment to test shock delivery. The system also provides a printed, or electronic log to alert
hospital personnel of any defibrillator functions or accessories that are compromised in
advance of a code.
Some R Series models include an optional transcutaneous pacemaker consisting of a pulse
generator and ECG sensing circuitry. The pacing option supports both demand and
asynchronous noninvasive pacing for adult, pediatric, or neonatal patients. OneStep™ Pacing
electrodes and OneStep Complete electrodes allow demand pacing and ECG monitoring
without separate ECG electrodes when the R Series is used with the OneStep™ Pacing cable.
Information regarding the unit’s operation, ECG, and other physiological waveforms are
displayed on a large 6.5 inch (16.5 cm) diagonal display which provides high contrast and
visibility under virtually all lighting conditions. Operating and warning messages are displayed
on the monitor, and the unit can also be configured with voice prompts to alert the user to unit
status. The R Series performs code readiness testing when the unit is OFF but connected to AC
power, when the defibrillator is initially turned on, and periodically during operation.
An annotating strip chart recorder is included to provide immediate documentation as well as
summary report functions about patient care and treatment in Manual mode.
A sophisticated data collection system, including summary report, printer, and multiple
communication ports is available for this unit. The stored data can be reviewed and archived on
a properly equipped personal computer using ZOLL CodeNet
®
Central software or ZOLL
RescueNet
®
Code Review software. R Series data files may be transferred to a PC using USB,
Compact Flash cards or Wi-Fi.
R Series products are intended for use in either AED mode or Manual mode by personnel
certified by appropriate federal, state, or local government authority to provide advanced life
support care.
