R Series Service Manual
9650-0903-01 Rev. J
3-1
Chapter 3
Disassembly Procedures
This chapter provides instructions on how to disassemble and reassemble the R Series unit, and includes the following sections:
“Removing the Cable Caddy” on page 3-3
“Removing the Handle” on page 3-6
“Removing the Recorder, AC Charger and Battery Well” on page 3-7
“Removing the Front Panel Assembly” on page 3-12
“Removing the Side Panels” on page 3-16
“Removing the Connector Panel and Bezel” on page 3-18
“Removing the ECG Input Connector” on page 3-20
“Removing the NIBP Assembly” on page 3-21
“Removing the System Brick Assembly” on page 3-23
“Discharging Capacitor” on page 3-28
“Removing the Communication Module” on page 3-29
“Disassembling the System Brick Assembly” on page 3-31
Required Equipment
•
#1 Philips head screwdriver
•
#2 Philips head screwdriver
•
Hex head screwdriver
•
Wooden stick
