C HAPTER 2 P RODUCT O VERVIEW
2–2 www.zoll.com 9650-0912-01 Rev. K
Table 2-1. R Series Unit Features
Item Description
1 Front panel Includes the display screen and primary controls.
2 Handle Integrated carrying handle.
3 External paddle well Holds paddles when not in use. Allows defib self-test when
paddles are stowed in their respective wells.
4 Beeper Emits R-wave detection beeps, defib charge Ready tones, and
alarm tones.
5 USB host connector
(Optional) (Reserved for future use — do not connect to any equipment.)
6 USB device connector For connecting the R Series defibrillator to a USB device. For
details, refer to “Event Records and Reports” on page 10-1.
7 Data card slot Holds a compact flash card for copying data stored in the
device’s internal memory. Accepts a CF memory card or a
WiFi card.
8 Defibrillator test port When not using OneStep electrodes or paddles, connect the
patient end of a OneStep cable to this port to allow device
checks.
9 Speaker Issues voice prompts.
10 Paper Compartment Holds the paper for the stripchart printer.
11 RELEASE button Allows access to the paper compartment.
12 Battery compartment Holds a rechargeable lithium ion battery pack.
13 Grounding post Electrical ground for biomedical test equipment.
14 AC mains connector For connecting the device to an AC power source.
15 Patient connectors For details, refer to “Patient Cables and Connectors” on
page 2-7.
