List of replacement parts, Main housing, List of replacement parts -2 – ZOLL R Series Monitor Defibrillator Rev J User Manual
Page 112
R Series Service Manual
4-2
9650-0903-01 Rev. J
List of Replacement Parts
Item numbers refer to the diagrams beginning on page 4-11.
See also “System Brick Replacement Parts” on page 3-31.
Part Number
Description
Item number
Main Housing
9310-2787-99
Rework, Main Housing
1
9301-0525-01
Assembly, PCB, PCB, Beeper Connector
19
9330-0750
Mount, Speaker, Beeper, Foam
18
9161-0034
Gasket, Beeper, Foam
17
9500-0760
Assembly, Cable, Paddle Shorting
12
9161-0025
Gasket, Printer, Flex Cable
4
9161-0026
Gasket, Battery Trough to Housing
2
9500-0746-01
Cable, Assembly, Beeper
16
9161-0302
Gasket, Paddle Latch
3
9320-0748
Panel, Connector, Ground Plane
10
9320-0751
Plane, Ground, Battery Board
11
0163-0401
Scr. PPH. #4.x 0.312". STL./ZNC.Hi/Lo
8
9161-0027
Gasket, Compact Flash to Housing
5
9330-0769
Pad, ESD, ECG Connector
14
9330-0756
Pad, ESD, Battery PCB
9
9330-0738
Pad, .70 X .50, rubber
6
9305-0903-01
Label, regulatory, UL, Large SN window
7
0140-0201
Ferrite Core Flat Cable Type
13
