R Series Service Manual
9650-0903-01 Rev. J 4-7
1009-0904-05 Assembly, Display Panel, ALS, EtCO
2
50
1009-0904-06 Assembly, Display Panel, BLS 50
1009-0933-01 Assembly, Handle 52
9302-0524-01 Assembly, Printer Interconnect Flex Cable 51
0155-0001 Magnetic.Sphere.Neodimium.0.187" dia 71
0163-2504 Scr. PPH.#2-32.X 0.312".STL.ZN.Hi/Lo 65
1009-0920-01 Assembly, Inner Frame BLS 61
1009-0923-01 Assembly, Pacer Door BLS 72
1009-0924-01 Assembly, Main Frame, VHB, adhesive 74
1009-0925-01 Assembly, Main Knob, BLS 63
1009-0936-01 Assembly, Pacer/Knob/O-Ring 54
9310-0790-01 Knob, with Spring, Main 53
9310-0803 Ring, Pacer 55
9310-0955 Filler, Pace 56
9310-0969 Pacer Knob, BLS 64
9310-0971 Knob, Index Ring BLS 62
9310-0977 Main Panel, No Pacer, BLS 66
9310-0986-01 Keypad, Front Panel, BLS/Plus with NIBP 60
9310-0994-01 Keypad Tiles, Monitor, BLS 69
9310-0994-02 Keypad Tiles, Defib, BLS 67
9310-0994-03 Keypad Tiles, AED, BLS 68
9310-0994-04 Keypad Tiles, Pacer, BLS 70
9500-0747 Cable, Assembly, Pace Encoder 59
Part Number Description Item number
