0 physical inspection of the unit, Physical inspection of the unit -4 – ZOLL R Series Monitor Defibrillator Rev J User Manual
Page 14
R Series Service Manual
1-4
9650-0903-01 Rev. J
1.0 Physical Inspection of the Unit
Tools Needed: None.
Test Setup: None.
Observe this...
Pass/Fail/NA
1.1
Housing
Is the unit clean and undamaged?
o
o
o
1.2
Does the unit show signs of excessive wear?
o
o
o
1.3
Is the handle undamaged?
o
o
o
1.4
Does the recorder door open and close properly?
o
o
o
1.5
Are input connectors clean and undamaged?
o
o
o
1.6
Are there any cracks in the housing?
o
o
o
1.7
Do the front panel or keypad buttons have any damage or cracks?
o
o
o
1.8
Are there any loose housing parts?
o
o
o
1.9
Do the paddle latches work properly?
o
o
o
1.10
Paddles
Do the adult and pedi plates have major scratches or show signs of damage?
o
o
o
1.11
Do the adult shoes slide on and off easily to expose the covered pedi plates?
o
o
o
1.12
Are the paddles clean (e.g., free of gel) and undamaged? (if applicable)
o
o
o
1.13
Cables
Are all cables free of cracks, cuts, exposed or broken wires?
o
o
o
1.14
Are all bend/strain reliefs undamaged and free of excessive cable wear?
o
o
o
