R Series Service Manual
9650-0903-01 Rev. J 4-5
1009-0917-04 Assembly, Kit, SpO
2
, Digital Board, ALS/Plus 101
1009-0917-05 Assembly, Kit, Digital Board, ALS/Plus, Nellcor 101
1009-0917-08 Assembly, Kit, Digital Board, SpO
2
/EtCO
2
/NIBP 101
1009-0917-09 Assembly, Kit, Digital Board, SpO
2
/EtCO
2
/NIBP, Nellcor 101
1009-0917-10 Assembly, Kit, EtCO
2
, Digital Board 101
1009-0910-02 Assembly, Shielded Analog System Board, 3/5 Lead 102
1009-0909-01 Assembly, PD Engine, Capacitor 103
1009-0926-01 Assembly, PD Engine, Capacitor 103
SpO
2
and EtCO
2
sub-assembly
1009-0899-04 Assembly, SpO
2
104
1009-0899-05 Assembly, SpO
2
, Nellcor 104
1009-0937-08 Assembly, SpO
2
/EtCO
2
/NIBP 104
1009-0937-09 Assembly, SpO
2
/EtCO
2
/NIBP, Nellcor 104
1009-0937-10 Assembly, EtCO
2
104
9330-0843 Thermal Pad, 1.0 x1.0 105
9330-0842 Thermal Pad, .75 x.75 106
0163-0102 Scr. #6-32, MCH,5/16", PNH,PHL,SST, Int 107
Charger and Side Panel
0163-0416 Scr. #6-32, MCH, 7/16", PNH, PHL, STL, Ext 36
1009-0900-01 Assembly, AC Charger 35
9161-0024 Gasket, Charger to Housing 34
9310-1784-01 Cap, End, Right, Assembly 37
Part Number Description Item number
