R Series Service Manual
1-32
9650-0903-01 Rev. J
18.5
Using the Index
SpO
2
Simulator, press the
BPM- softkey until the heart rate is 50 BPM.
The
SpO
2
saturation of 96-100% displays on the unit.
The heart rate of 46-54 BPM displays on the R Series monitor.
o
o
o
o
18.6
Using the Index
SpO
2
Simulator, press the 02+
softkey until the SpO
2
output is at 72%.
The
SpO
2
saturation of 69-74% displays on the unit.
The heart rate of 46-54 BPM displays on the R Series monitor.
o
o
o
o
18.7
Press the OPTIONS softkey. Press TRACES.
Press TRACE 2. Select
SpO
2
.
Plethysmographic waveform appears on the ZOLL display.
o
o
18.8
Press RECORDER.
The plethysmographic waveform prints on the strip chart paper.
o
o
18.9
Press RECORDER to stop printing.
Verify that the recorder stops.
o
o
18.10
Using the Index
SpO
2
Simulator, press the
BPM- softkey until the heart rate is at 230 BPM.
The
SpO
2
saturation rate of 69-74% displays on the unit.
The heart rate in the heart position of 226-234 BPM displays on the monitor.
o
o
18.11
Press RECORDER.
Verify that the waveform is printed at the correct rate.
Press RECORDER to stop printing.
o
o
18.12
Press RECORDER. Remove the Masimo
patient cable.
Verify that the recorder stops.
o
o
Record your results on the Maintenance Test Checklist.
Do this...
Observe this...
Pass/Fail
