Back panel, Pcb brick assembly – ZOLL R Series Monitor Defibrillator Rev J User Manual
Page 113
R Series Service Manual
9650-0903-01 Rev. J
4-3
9310-0894
Isolator, ECG
15
Back Panel
0140-0202
Ferrite Core Flat Cable Type
100
0162-0033
Washer.Ribbed Lock.M14. 15mm ID.x 22mm OD.x 2mm.ZINC.
25
0163-0029
Washer.Lock Int.7/16.0.456"ID.0.765"OD.0.036"THK.SS
28
0163-0286
Scr. #2-56, MCH, 5/16", PNH, PHL, STL, Int
21
0163-0401
Scr. PPH. #4.x 0.312".STL./ZNC.Hi/Lo
8
0163-2500
Nut.Hex.7/16 - 24 Unf.Chrome Plated Brass Panel Nut
26
0501-0001
Ty-Rap cable tie STD 18 LB .093W X 3.62 L
99
1009-0902-01
Assembly, Communications Module
20
1009-0929-01
Assembly, Cable Organizer
33
1009-0930-01
Assembly, NIBP Fitting-O-ring
30
9150-0503
Connector, MFC, Assembly
31
9161-0032
Gasket, Compact Flash, USDB
23
9310-2786
Connector Panel
29
9330-0717
Mount, Adhesive, Color inverter PCB
22
9500-0764
Assembly, Cable, SYNC, IN/OUT, ECG, RS232
27
9500-0902
Cable, Isolated Power Supply to EtCO2
24
9500-0991
Assembly, SpO
2
, internal connector
32
PCB Brick Assembly
Complete
0140-5622
Mag.Round Cable Core assembly, Ferrite
90
Part Number
Description
Item number
