R Series Service Manual
4-4 9650-0903-01 Rev. J
0163-0286 Scr. #2-56, MCH, 5/16", PNH, PHL, STL, Int 21
0163-1231 Scr. PHH PNH. #6.0.500" Lg.STL/ZN.ZI.Hi/Lo 88
0501-0002 Cable tie, 8" X 0.1" Black UV 95
1009-0901-01 Assembly, System Brick 85
1009-0901-02 Assembly, Options, System Brick 85
1009-0901-03 Assembly, System Brick, ALS/BLS, no physiological monitoring 85
1009-0901-04 Assembly, Options, System Brick, ALS/BLS, SpO
2
85
1009-0901-05 Assembly, System Brick, Nellcor 85
1009-0901-08 Assembly, Options, System Brick, SpO
2
/EtCO
2
/ NIBP 85
1009-0901-09 Assembly, Options, System Brick, Nellcor, SpO
2
/EtCO
2
/NIBP 85
1009-0901-10 Assembly, Options, System Brick, EtCO
2
85
1009-0928-01 Assembly, Chassis, NIBP option 87
1009-0931 Assembly, Anchor, NIBP Pump, VHB Tape 86
9301-0526-01 Assembly, PCB, ECG Interconnect, Flex Cable 93
9301-1512-02 Assembly, PCB, ECG Input Connector, 3/5 Lead 92
9310-1789 Connector Panel Bezel 91
9330-0664 Retainer Pad, ECG 94
9330-0933 Strip, VHB, CF/USB 96
9330-0935 Pad, VHB, CF/USB 97
9330-0944 Foam, Tape, VHB 4952, 1.25 X .50 89
9500-0770 Cable Assembly, Hi/Lo Current, Battery to P/D Engine 98
Sub-assembly
1009-0917-03 Assembly, Kit, Digital Board, No options ALS/BLS 101
Part Number Description Item number
