0 3 and 5 leads test, 3 and 5 leads test -8 – ZOLL R Series Monitor Defibrillator Rev J User Manual
Page 18
R Series Service Manual
1-8
9650-0903-01 Rev. J
3.0 3 and 5 Leads Test
Tools Needed: Impulse 4000,3 lead adapter (part # 8009-0762-XX) or 3 lead cable, and 5 lead cable. If applicable, test each cable separately.
Test Setup:
1. The R Series unit must be configured to display ECG LEAD OFF message.
2.
Connect the lead wires appropriate to each test to the Fluke Biomedical 4000 or equivalent.
Do this...
Observe this...
Pass/Fail/NA
3.1
Turn the selector switch to MONITOR (for AED
units turn to ON.) Select leads.
No ECG LEAD OFF message displayed.
o
o
o
3.2
Disconnect one lead from the Impulse 4000.
The ECG LEAD OFF message displays within 3 seconds (if configured).
o
o
o
3.3
Reconnect the lead. Repeat step 3.2 with the
remaining leads.
Wait for ECG LEAD OFF message to clear from the display (if configured).
o
o
o
3.4
If applicable, repeat 3.2 and 3.3 for the
remaining cable(s).
NOTE: If heart rate alarm sounds, press and hold the ALARM SUSPEND
button for 4 seconds to disable the alarms.
o
o
o
Record your results on the Maintenance Test Checklist.
