ECG Monitoring Setup
9650-0805-01 Rev. A
Propaq MD Operator’s Guide
6-7
Select a current waveform source, and the unit displays the waveform immediately. If you
select a waveform source that is not currently available, the unit displays the message, LEAD
FAULT.
For more information on how to configure the display of waveforms on the Propaq MD unit,
see Chapter 3, Monitoring Overview.
