P ATIENT D ATA
16–2 www.zoll.com 9650-0805-01 Rev. A
Capturing a Data Snapshot
Press the Snapshot button ( ) on the front panel to capture a 24-second period of numeric and
waveform patient data. The unit captures 12 seconds proceeding and 12 seconds following the
button press.
The Propaq MD unit can store a minimum of 32 snapshots, including
• Monitor snapshots
• Defibrillator snapshots
• Treatment snapshots
• Pacer snapshots
• Alarm snapshots
Reviewing and printing snapshots
You can perform this procedure from any main display screen.
1. Press the Home/Display button ( ) repeatedly until the Trends window displays.
2. Use the navigation keys to get to the Trends window.
3. Press Select button to scroll through the list of trends.
Note: The snapshots have a snapshot icon next to the time stamp.
4. Select the desired snapshot from the Trends list and press Select. The snapshot numeric data
displays.
5. To print the data and the snapshot waveforms, highlight Print this Snapshot and press
Select.
Treatment Summary Report
The Treatment Summary Report is a report that shows all of the treatment events related to a
patient such as defibrillation/pacer events, alarm events, and treatment snapshots. It is helpful
to print out this report at the end of a case.
TREATMENT SUMARY REPORT
Name: John Doe
09:14:14 New Case ID
ID: Patient 0015 Patient Mode: Adult 09:14:14 System On
Start Time: 09/14/10 09:14:14 09:14:14 Patient Mode Adult
Last Event: 09/14/10 09:43:40 09:14:14 Some Alarm Limits Disabled
Elapsed Time: 00:29:48 # Events: 09:14:20 Self Test Passed
Total Shocks: 1 09:14:43 Treatment Snapshot: ASA
Total Pace Time: 00:00:00
Total 12 Leads: 0
Dept: ICU
Unit:
S/N: 0 SW: 00.00.00.00
