Defibrillator
9650-0805-01 Rev. A
Propaq MD Operator’s Guide
A-3
* For all energy levels, accuracy is equal to either ±15% or 3 joules, whichever is greater.
The Propaq MD Rectilinear Biphasic waveform employs the same first and second phase
timing, similar first and second phase currents/voltages, and essentially the same mechanisms
for controlling defibrillation waveshape as the ZOLL R Series
®
defibrillator. The R Series and
Propaq MD defibrillation waveforms are considered substantially equivalent.
Figures A-1 through A-20 show the Rectilinear Biphasic waveforms that are produced when
the Propaq MD defibrillator is discharged into loads of 25, 50, 75, 100, 125, 150, and 175 ohms
at each energy setting.
Table A-2.
Delivered Energy at Every Defibrillator Setting into a Range of Loads
Selected
Energy
Load
25
50
75
100
125
150
175
Accuracy*
1 J
1 J
1 J
1 J
1 J
1 J
1 J
1 J
±15%
2 J
1 J
2 J
2 J
2 J
2 J
2 J
2 J
±15%
3 J
2 J
3 J
3 J
3 J
3 J
3 J
3 J
±15%
4 J
3J
4 J
4 J
5 J
5 J
5 J
4 J
±15%
5 J
3 J
5 J
6 J
6 J
6 J
6 J
6 J
±15%
6 J
4 J
6 J
7 J
7 J
7 J
7 J
7 J
±15%
7 J
5 J
7 J
8 J
8 J
8 J
8 J
8 J
±15%
8 J
5 J
8 J
9 J
9 J
10 J
9 J
9 J
±15%
9 J
6 J
9 J
10 J
11 J
11 J
11 J
10 J
±15%
10 J
7 J
10 J
12 J
12 J
12 J
12 J
12 J
±15%
15 J
10 J
16 J
17 J
18 J
18 J
18 J
17 J
±15%
20 J
14 J
21 J
23 J
24 J
24 J
24 J
23 J
±15%
30 J
21 J
32 J
35 J
36 J
37 J
36 J
35 J
±15%
50 J
35 J
54 J
59 J
61 J
62 J
61 J
59 J
±15%
70 J
49 J
76 J
83 J
85 J
87 J
86 J
83 J
±15%
85 J
60 J
92 J
101 J
104 J
106 J
104 J
101 J
±15%
100 J
71 J
109 J
119 J
122 J
125 J
123 J
119 J
±15%
120 J
85 J
131 J
143 J
147 J
150 J
147 J
143 J
±15%
150 J
107 J
164 J
180 J
183 J
188 J
184 J
179 J
±15%
200 J
142 J
230 J
249 J
253 J
269 J
261 J
260 J
±15%
