Monitor Controls and Indicators
9650-000820-01 Rev. B
Propaq M Operator’s Guide
2–5
Figure 2-2.
Propaq M Display Screen
Color coding
To differentiate information for various parameters, the unit displays each type of information
in a specific user-configurable color.
Date and time
Patient mode
Battery status
Time elapsed
Quick
access
keys
Message
Waveform
SpO
2
data
CO
2
data
Respiration rate
NIBP data
Heart rate
Current temp
03/23/2012 12:34:56
Adult
00:17:43
I, II,
III...
12
CO
2
IBP
1 cm/mV
II
HR bpm
80
121
79
(96)
NIBP mmHg
38
12
BR
CO2 mmHg SpO2 %
97
T1 ºF
98.6
Status queue
