C HAPTER 13 12-L EAD ECG I NTERPRETIVE A NALYSIS
13-6 www.zoll.com 9650-000820-01 Rev. B
Avoid placing electrodes over tendons and major muscle masses.
Place the precordial electrodes across the chest in the following locations:
Electrode Placement
V1/C1 Fourth intercostal space, at the patient’s right sternal margin.
V2/C2 Fourth intercostal space, at the patient’s left sternal margin.
V3/C3 Midway between V2/C2 and V4/C4.
V4/C4 Fifth intercostal space, on the patient’s midclavicular line.
V5/C5 Patient’s left anterior axillary line, at the horizontal level of V4.
V6/C6 Patient’s left midaxillary line, at the same horizontal level as V4 and V5.
